Download Window 10 Enterprise 1903 with the Media Creation Tool (including en-GB and other language versions)

The March (or that May?) 2019 version of Windows 10 is now availabe to download using the Media Creation Tool. Using the GUI you can download the consumer ISO which contains the Home, Professional and Education SKUs of Windows 10.

If you want to download the Enterprise version of Windows 10, but don’t have access to Microsoft VLSC, Visual Studio or Action Pack subscriptions, it is possible to download it using the Media Creation Tool if you know the right command line switches.

To download Windows 10 Enterprise 1903 using the Media Creation Tool, log in with a local administrator account (for some reason it isn’t good enough to run the tool using Run as administrator, you actually do have to be logged in as an administrator) and download the tool. Open a CMD prompt and change directory to the directory you saved the Media Creation Tool in, and enter the following command:

MediaCreationTool1903.exe /Eula Accept /Retail /MediaArch x64 /MediaEdition Enterprise

When you’re prompted for a product key, you can use the Windows 10 Enterprise KMS client key from this site on Microsoft Docs.

This will download an ISO that contains the various Enterprise SKUs (Enterprise, Enterprise N,  Education, Education N, Professional and Professional N) with en-US installed and set to default. If you’d prefer to get en-GB, use the following command:

MediaCreationTool1903.exe /Eula Accept /Retail /MediaLangCode en-GB /MediaArch x64 /MediaEdition Enterprise

This will download an ISO containing the same SKUs as above, but with en-GB installed and set to default.

As far as I can tell, this works for any of the language pack region tags listed on this site. So for example, to download Windows 10 Enterprise 1903 with French installed and set to the default language, you can use this command:

MediaCreationTool1903.exe /Eula Accept /Retail /MediaLangCode fr-FR /MediaArch x64 /MediaEdition Enterprise

If you want to download the 32-bit version of Windows 10 Enterprise instead, you should change /MediaArch to x86.

When you have downloaded the ISO you may unpack it to find that the it does not contain an install.wim, but instead contains install.esd in the sources directory. Depending on what you are doing, you may need the .wim file (for example, if you’re planning to use it with SCCM). Thankfully obtaining a .wim file from the .esd is quite straightforward using DISM.

Open a CMD prompt and use the following command (changing the path for /WimFile to match where your install.esd file is):

dism.exe /Get-WimInfo /WimFile:C:\Temp\Windows10_1903\sources\install.esd

This will list each of the SKUs in the install.esd file. Make a note of the index of the SKU you want (in my case, I want the Enterprise SKU which is index 3).

DISM Get-WimInfo

Now use the following command to create an install.wim file which contains the SKU you want:

dism.exe /Export-Image /SourceImageFile:C:\Temp\Windows10_1903\sources\install.esd /SourceIndex:3 /DestinationImageFile:C:\Temp\Windows10_1903\sources\install.wim /Compress:max /CheckIntegrity

Make sure the path for /SourceImageFile and /DestinationImageFile are correct for you and change the /SourceIndex to match the index you noted earlier.

dism.exe /Export-Image /SourceImageFile:C:TempWindows10_1903sourcesinstall.esd /SourceIndex:3 /DestinationImageFile:C:TempWindows10_1903sourcesinstall.wim /Compress:max /CheckIntegrity



Once that is done you can delete the install.esd file if you want, to save space.

This process also works with earlier versions of Windows 10.

Installing Remote Server Administration Tools (RSAT) for Windows 10 1809 (including SCCM deployment) (Part 2)

In the first part of this guide I stated that in order to install RSAT in Windows 10 1809 and above, Windows needs to be able to reach the Internet to download the source files. This is due to RSAT being a feature-on-demand in 1809 and above, so the files are not included on the disk but instead hosted online and downloaded when required.

Well it turns out the source files can be downloaded, if you have access to Microsoft Volume Licensing Service Center or Visual Studio downloads. Search for “features on demand” and make sure you download the latest ones for 1809 (in my Visual Studio downloads portal it is listed as “Windows 10 Features on Demand, version 1809 (Updated Sept 2018)”).

Once you have downloaded the ISO, you can use it as the source location when installing RSAT with PowerShell. Say, for example, you mount the ISO as the F: drive, you would use the following command:

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'RSAT')} | %{Add-WindowsCapability -Online -LimitAccess -Name $_.Name -Source F:\ }

However, there is a lot more on that disk than just the files required for RSAT, and if you wish to use this in an SCCM package you will want to sanitise it a bit. The whole disk contains 4.6 GB of files, however the ones we need for RSAT are only about 500 MB.

To create a package using only the files you need for RSAT, create a folder somewhere called RSATSource and copy the files with the following names (there will be multiple files per search, you need all of them):

Microsoft-Windows-ActiveDirectory-DS-LDS-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-BitLocker-Recovery-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-CertificateServices-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-DHCP-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-DNS-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-FailoverCluster-Management-Tools-FOD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-FileServices-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-GroupPolicy-Management-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-IPAM-Client-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-LLDP-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-NetworkController-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-NetworkLoadBalancing-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-RemoteAccess-Management-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-RemoteDesktop-Services-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-ServerManager-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-Shielded-VM-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-StorageMigrationService-Management-Tools-FOD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-StorageReplica-Tools-FoD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-SystemInsights-Management-Tools-FOD-Package~31bf3856ad364e35~amd64~
Microsoft-Windows-VolumeActivation-Tools-FoD-Package~31bf3856ad364e35~amd64~

You will also need to copy the “metadata” folder and the file “FoDMetadata_Client.cab”. With these files copied into their own folder, you can change the PowerShell to:

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'RSAT')} | %{Add-WindowsCapability -Online -LimitAccess -Name $_.Name -Source C:\RSATSource }

Obviously replace C:\RSATSource with the location of the source folder you copied all those files into.

Creating an SCCM application to deploy RSAT

Since I already wrote this up in Part 1 of this guide, this part is mostly just a rehash of that. However, there is one change to the script so that it now uses the local packaged source, rather than going online to download the source.

To create an application in SCCM you will need three things: An install command, an uninstall command and a detection method. To cover the install and uninstall command, let’s create a PowerShell script with an install and uninstall function that can be called from the command line. The following PowerShell script is used to install and uninstall all RSAT components; if you want to pick and choose the ones you install or uninstall, modify it accordingly.

## Install all RSAT components

Function InstallRSAT {

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch         'Installed') -and ($_.Name -match 'RSAT')} | %{Add-WindowsCapability -Online -LimitAccess -Name $_.Name -Source $PSScriptRoot\RSATSource}

}



## Uninstall each RSAT component so that no dependancies are left behind

Function UninstallRSAT {

Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.BitLocker.Recovery.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.CertificateServices.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.DHCP.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.Dns.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.FailoverCluster.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.FileServices.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.IPAM.Client.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.LLDP.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.NetworkController.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.NetworkLoadBalancing.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.RemoteAccess.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.RemoteDesktop.Services.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.Shielded.VM.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.StorageMigrationService.Management.Tools')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.StorageReplica.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.SystemInsights.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.VolumeActivation.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.WSUS.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.ActiveDirectory.DS-LDS.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.GroupPolicy.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.ServerManager.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

}



## Get the parameter passed to the script

$DeploymentType=$args[0]



## Run the install or uninstall function

if ($DeploymentType -eq "Uninstall") {

UninstallRSAT
}


else {

InstallRSAT
}

Copy that script and save it as Install-RSAT.ps1. Create your application in SCCM and go through the wizard, giving it a name, publisher and version. The source will be the location where you saved Install-RSAT.ps1. Don’t forget to also copy your RSATSource folder to this location! When you get to the install and uninstall commands in the wizard, you can use the following commands:

To install:
powershell.exe -ExecutionPolicy Bypass -File .\Install-RSAT.ps1 -DeploymentType Install

To uninstall:
powershell.exe -ExecutionPolicy Bypass -File .\Install-RSAT.ps1 -DeploymentType Uninstall

Next up is the detection method. For this, you will need to use a PowerShell detection method. The PowerShell will simply check that the RSAT optional components have their install state set to Installed:

$installed = Get-WindowsCapability -Online | where name -like RSAT* | where state -like Installed | select name

if ($installed) {
    return $true
}

That should be all you need! Deploy that to a Windows 10 1809 device and the user should be able to install RSAT from Software Center.

Windows Vista Ultimate Signature Edition

On January 30th, 2007 Microsoft released their much-delayed successor to Windows XP, Windows Vista. It released with far too many editions, which Microsoft slowly whittled down to just a few over the years leading up to the release of Windows 10.

One of the lesser known editions that Microsoft released was Windows Vista Ultimate Signature Edition. This was unique among the special signed / event orientated releases of Windows in that it was commercially available for anyone to purchase rather than being limited to handouts at the launch event. It was available in the US and cost $10 more than the regular Ultimate edition, getting you exactly $0 worth of additional stuff, unless you really like boxes with a print of Bill Gates’ signature on them.

Windows Vista Ultimate Signature Edtion front

This was limited to 25,000 copies, and, like the Windows 95 Special Edition, only got you an upgrade license of Windows Vista – not even a full license! Like the Windows 95 Special Edition there is a printed note from Bill Gates on the inside cover of the box that reads:

I’ve always been inspired by the limitless potential of technology. And I believe that its definition is never fixed, but instead is an ongoing collaboration among technical professionals and enthusiasts – a group of people who are inspired by the challenge of testing the limits of technology, redefining its boundaries, and setting new standards for innovation and progress. At Microsoft, we feel very fortunate to be a part of this effort. And so, as thanks, we hope you will enjoy this Signature Edition of Windows Vista Ultimate. It represents both our best work and our vision of what the future might hold.

Bill Gates

This wasn’t the only special edition of Windows Vista that Microsoft released. They also released a (PRODUCT) RED edition in support of raising awareness and helping to eliminate AIDS in Africa. This was originally a Dell exclusive that only shipped with certain Dell PCs but got its own boxed release that was available from December 15th, 2008. This edition came with some additional desktop wallpapers, a screensaver, two Sidebar gadgets and a DreamScene wallpaper (remember those things?)

If you’re interested in any other special Windows editions please check out my article about Windows 95 Special Edition and Windows 7 Ultimate Signature Edition.

Switch from Legacy BIOS to UEFI on existing installs of Windows Server 2016 (and 2012 / 2012 R2)

With most modern servers now shipping with UEFI enabled by default and many virtual hypervisor platforms supporting it for guest VMs as well, you may wish to switch your existing installations of Windows Server 2012, 2012 R2 or 2016 from booting with legacy BIOS to booting with UEFI. Thanks to a small tool introduced by Microsoft in Windows 10 1703, MBR2GPT.EXE, this can be done very easily.

You will need to download a copy of Windows 10 1703 or later in order to follow this guide as you need a copy of MBR2GPT.EXE and you need to boot your server into the version of WinPE that comes with these releases of Windows 10. You cannot run the tool in versions of Windows prior to 1703 (which, technically, Window Server 2016 is as it uses the same codebase Windows 10 1607).

Make certain your platform supports UEFI booting before continuing with this guide. If it does not, you will no longer be able to boot into Windows after you have changed the partition table from MBR to GPT.

If this process fails it has the potential to make your server unbootable, corrupt your data and cause lengthy downtime. Make certain you have an adequate backup of your server and a restoration process in place before proceeding.

Okay, with the big scary warnings out of the way, let’s get going!

First start by loading the Window 10 1703 (or later) ISO onto a USB drive, DVD, or if you’re following this process on a VM, mount it directly on the VM. Restart your server and boot the server from the Windows installation media. Click Next on the language selection screen and on the next screen click Repair your computer.

When the options screen comes up select Troubleshoot, and in Advanced Options select Command Prompt. You’ll find yourself at the command prompt in X:\Sources. Change directory to X:\Windows\system32 and start diskpart. Type list disk to list the disks attached to the system and note down the one that contains the OS. This will likely to be disk 0 but may not be depending on your servers’ disk layout.

diskpart List Disk

Exit diskpart and type MBR2GPT.exe /validate /disk:0. This will run the MBR2GPT tool on your OS disk to validate that it is ready for the conversion. If it is successful, run MBR2GPT.exe /convert /disk:0 and wait for the conversion to complete – it should not take long.

MBR2GPT Convert

That’s it for the conversion. Now restart your server, enter setup and enable UEFI booting. Save and exit and Windows should boot right up without any issues.

Now there is some optional clean up you can do. How optional it is depends on if you’ll ever want to extend the size of the drive. On a physical server it is unlikely your partition doesn’t already use the full size of the drive, however on a VM where it is possible to increase the size of the disk, you may have need to extend it in the future. It also depends on if you use BitLocker or not – more on that in a moment.

Here’s the deal. In Windows, open a command prompt and start diskpart. Type select disk 0 and then list partition. You will see three partitions – a 500 MB recovery partition, your OS partition and a 100 MB EFI system partition. That 500 MB partition is no longer in use since you no longer have an MBR partition. The new system partition is that 100 MB one at the end, and because it is at the end it will block you extending your OS partition. Fortunately, you can reuse that 500 MB of space and put the EFI system partition there instead.

If you use BitLocker to encrypt your drive the 500 MB partition also contains the unencrypted system files needed to start your computer. In this case, you cannot delete the partition. If you really need to be able to extend your partition in the future you can either unencrypt your drive, move the partition and then re-encrypt it, or use a third-party partitioning tool to move the EFI system partition to the front of the disk.

If you want to complete the partition clean up, here’s what to do. First, reboot the server and use the same steps as earlier with your Windows 10 installation media to end up back at the command prompt. From here, enter diskpart and type select disk 0 and then list partition. Note down which partitions are the 500 MB recovery partition and 100 MB system partition (typically these will be partition 1 and partition 3). Proceed to delete these partitions by first selecting them and then deleting them, using the commands select partition 1 followed by delete partition override and then select partition 3 followed by delete partition override.

diskpart Delete Partitions

Now create a new EFI system partition at the front of the disk using the command create partition efi size=100, format it using format quick fs=fat32 and assign it a drive letter using assign letter=s. Next, use the list volume command to get a list of volumes and make a note of the drive letter your OS drive is on (very likely C).

diskpartListVolume

Exit diskpart and type bcdboot C:\Windows /s S: to copy the necessary system files to the new EFI system partition.

Finally, enter diskpart one last time, type select disk 0 and then select partition 2 and then type extend to reclaim that 100 MB of space at the end of the drive (may as well, right?) This will leave you with 2 partitions – the 100 MB EFI system partition at the beginning of the drive and your OS partition. Exit diskpart and restart your server.

diskpartExtendPartition

And that’s it, the server now boots with UEFI and the partitions are all tidied up1.

1The astute among you will have realised that actually, the partitions aren’t quite as clean as you might like. Due to the old system partition being 500 MB and the new one being 100 MB, there is now 400 MB of unused space between the system partition and the OS partition. You have a few options here. The first, and simplest, is to actually create the new EFI partition with 500 MB of space rather than 100 MB. It doesn’t need that much space, but it will look better in Disk Management not having that random unused space between the partitions. Your second option is to simply leave it there, which could be beneficial in the future. If you ever turn on BitLocker it will need to create a 350 MB partition to store the unencrypted system files needed to boot your computer, and it can do so inside that 400 MB of space. Your third option is to use a third-party partitioning tool which is capable of extending your OS partition into the space in front of it, which is something that diskpart cannot do.

Installing Remote Server Administration Tools (RSAT) for Windows 10 1809 (including SCCM deployment) (Part 1)

Update, February 2019: Since writing this in October 2018 I have learnt that it is possible to download the files needed if you have access to certain Microsoft resources. If you do not, this guide is still relevant. However you may wish to read this and Part 2 before taking any action.

Starting in Windows 10 1809 and continuing in future versions of Windows 10, the Remote Server Administration Tools are an optional feature that can be installed from within the OS, rather than you having to download them from Microsoft separately. This new approach fixes the issue that the tools would be uninstalled every time you install a Windows 10 feature update.

This does have a downside though, which is that Windows must go out to an update source to get the source files for RSAT (they are not included in the /Sources/sxs directory like the .NET 3 Framework source files are). This means you may have to allow clients to go out to Windows Update if they are installing RSAT!

The quick and dirty way to install all RSAT components is to open an administrative PowerShell window and use the command:

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'RSAT')} | %{Add-WindowsCapability -Name $_.Name -Online }

This will look for all features that have RSAT in the name and install them.

If you get an error 0800f0954 it means the source location could not be reached. This may be because the machine you’re attempting to install RSAT on doesn’t have internet access or is configured to go to a WSUS or SCCM server for updates. If it’s the latter, you can enable a GPO which allows Windows to go to Windows Update for optional component installations only (while still getting regular updates from WSUS or SCCM). This GPO is in:

Computer Configuration > Administrative Templates > System > Specify settings for optional component installation and component repair

Tick the Download repair content and optional features directly from Windows Update instead of Windows Server Update Services (WSUS) and click OK to set the GPO. You can test this with local group policy to make sure it fixes the issue before deploying it to everyone!

Each of the RSAT components can also be installed individually if you don’t wish to install all of them. The list of RSAT components can be found on this Microsoft Docs page. Use the following PowerShell command to install the component you want, changing the name to match the component you want to install (these are listed as capability names on the linked Microsoft Docs page):

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.BitLocker.Recovery.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

You can install multiple components by simply duplicating the command and changing the name to match another component.

Uninstalling is a little more complicated as you cannot simply use the same catch-all PowerShell command to uninstall as you can to install. This is because some of the RSAT components have dependencies and if you try to uninstall them all the dependancies  will remain installed. To get around this, you can uninstall them in a specific order to ensure that all the dependant components are removed first.

I use the following order:

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.BitLocker.Recovery.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.CertificateServices.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.DHCP.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.Dns.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.FailoverCluster.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.FileServices.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.IPAM.Client.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.LLDP.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.NetworkController.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.NetworkLoadBalancing.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.RemoteAccess.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.RemoteDesktop.Services.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.Shielded.VM.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.StorageMigrationService.Management.Tools')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.StorageReplica.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.SystemInsights.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.VolumeActivation.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.WSUS.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.ActiveDirectory.DS-LDS.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.GroupPolicy.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.ServerManager.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Making sure that the last three are Rsat.ActiveDirectory.DS-LDS.Tools~~~~0.0.1.0, Rsat.GroupPolicy.Management.Tools~~~~0.0.1.0 and Rsat.ServerManager.Tools~~~~0.0.1.0 seems to fix issues with dependant components.

Creating an SCCM application to deploy RSAT

To create an application in SCCM you will need three things: An install command, an uninstall command and a detection method. To cover the install and uninstall command, let’s create a PowerShell script with an install and uninstall function that can be called from the command line. The following PowerShell script is used to install and uninstall all RSAT components; if you want to pick and chose the ones you install or uninstall, modify it accordingly.

## Install all RSAT components
Function InstallRSAT {
    Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'RSAT')} | %{Add-WindowsCapability -Name $_.Name -Online}
}

## Uninstall each RSAT component so that no dependancies are left behind
Function UninstallRSAT {
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.BitLocker.Recovery.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.CertificateServices.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.DHCP.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.Dns.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.FailoverCluster.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.FileServices.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.IPAM.Client.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.LLDP.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.NetworkController.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.NetworkLoadBalancing.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.RemoteAccess.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.RemoteDesktop.Services.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.Shielded.VM.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.StorageMigrationService.Management.Tools')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.StorageReplica.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.SystemInsights.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.VolumeActivation.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.WSUS.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.ActiveDirectory.DS-LDS.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.GroupPolicy.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.ServerManager.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
}

## Get the parameter passed to the script
$DeploymentType=$args[0]

## Run the install or uninstall function
if ($DeploymentType -eq "Uninstall") {
    UninstallRSAT
}

else {
    InstallRSAT
}

Copy that script and save it as Install-RSAT.ps1. Create your application in SCCM and go through the wizard, giving it a name, publisher and version. The source will be the location where you saved Install-RSAT.ps1. When you get to the install and uninstall commands in the wizard, you can use the following commands:

To install:
powershell.exe -ExecutionPolicy Bypass -File .\Install-RSAT.ps1 -DeploymentType Install

To uninstall:
powershell.exe -ExecutionPolicy Bypass -File .\Install-RSAT.ps1 -DeploymentType Uninstall

Next up is the detection method. For this, you will need to use a PowerShell detection method. The PowerShell will simply check that the RSAT optional components have their install state set to Installed:

$installed = Get-WindowsCapability -Online | where name -like RSAT* | where state -like Installed | select name
if ($installed) {
    return $true
}

That should be all you need! Deploy that to a Windows 10 1809 device and the user should be able to install RSAT from Software Center… as long as their device can go online to reach the source files.

Download Window 10 Enterprise 1809 with the Media Creation Tool (including en-GB and other language versions)

Update 22/05/2019: Psst! Looking for Windows 10 Enterprise 1903? Then look right here!

The October 2018 release of Windows 10 has just dropped and is now availabe to download using the Media Creation Tool. Using the GUI you can download the consumer ISO which contains the Home, Professional and Education SKUs of Windows 10.

If you want to download the Enterprise version of Windows 10, but don’t have access to Microsoft VLSC or Action Pack subscriptions, it is possible to download it using the Media Creation Tool if you know the right command line switches.

To download Windows 10 Enterprise 1809 using the Media Creation Tool, log in with a local administrator account (for some reason it isn’t good enough to  run the tool using Run as administrator, you actually do have to be logged in as an administrator) and download the tool. Open a CMD prompt and change directory to the directory you saved the Media Creation Tool in, and enter the following command:

MediaCreationTool1809.exe /Eula Accept /Retail /MediaArch x64 /MediaEdition Enterprise

When you’re prompted for a product key, you can use the Windows 10 Enterprise KMS client key from this site on Microsoft Docs.

This will download an ISO that contains the various Enterprise SKUs (Enterprise, Enterprise N,  Education, Education N, Professional and Professional N) with en-US installed and set to default. If you’d prefer to get en-GB, use the following command:

MediaCreationTool1809.exe /Eula Accept /Retail /MediaLangCode en-GB /MediaArch x64 /MediaEdition Enterprise

This will download an ISO containing the same SKUs as above, but with en-GB installed and set to default.

As far as I can tell, this works for any of the language pack region tags listed on this site. So for example, to download Windows 10 Enterprise 1809 with French installed and set to the default language, you can use this command:

MediaCreationTool1809.exe /Eula Accept /Retail /MediaLangCode fr-FR /MediaArch x64 /MediaEdition Enterprise

If you want to download the 32-bit version of Windows 10 Enterprise instead, you should change /MediaArch to x86.

When you have downloaded the ISO you may unpack it to find that the it does not contain an install.wim, but instead contains install.esd in the sources directory. Depending on what you are doing, you may need the .wim file (for example, if you’re planning to use it with SCCM). Thankfully obtaining a .wim file from the .esd is quite straightforward using DISM.

Open a CMD prompt and use the following command (changing the path for /WimFile to match where your install.esd file is):

dism.exe /Get-WimInfo /WimFile:C:\Temp\Windows10_1809\sources\install.esd

This will list each of the SKUs in the install.esd file. Make a note of the index of the SKU you want (in my case, I want the Enterprise SKU which is index 3).

DISM Get-WimInfo

Now use the following command to create a install.wim file which contains the SKU you want:

dism.exe /Export-Image /SourceImageFile:C:\Temp\Windows10_1809\sources\install.esd /SourceIndex:3 /DestinationImageFile:C:\Temp\Windows10_1809\sources\install.wim /Compress:max /CheckIntegrity

Make sure the path for /SourceImageFile and /DestinationImageFile are correct for you and change the /SourceIndex to match the index you noted earlier.

DISM Convert ESD

Once that is done you can delete the install.esd file if you want, to save space.

This process also works with earlier versions of Windows 10.

Updating Office 365 client with SCCM

Each release of SCCM current branch has been improving how it manages Office 365 clients, and the last couple of versions have improved the user experience the most. The only real issue remaining is that, under certain circumstances, the user will be prompted to reboot once the Office 365 update is complete. This reboot is not actually necessary, however. Here is how to go about setting up SCCM so that it delivers Office 365 updates to users without prompting them for an unnecessary reboot.

For starters, make sure your SCCM environment is syncing Office 365 client updates. To do this open the SCCM console and navigate to Administration > Site Configuration > Sites, select your site and select Configure Site Components > Software Update Point. Click on the Products tab and make sure Office 365 Client is ticked. Click OK to close that dialog and then head over to Software Library > Software Updates > All Software Updates and select Synchronize Software Updates in the ribbon.

Another thing to check is that the Office 365 client agent on users’ machines is configured to be managed by SCCM. You can set this in the Client Settings of SCCM. Go to Administration > Client Settings and click properties on the device settings policy your clients receive. Select Software Updates and ensure that Enable management of the Office 365 Client Agent is set to Yes.

ClientSettingsOffice365ClientAgent

Once that’s had time to process, create an Automatic Deployment Rule to push out the updates each month (or on whatever schedule you prefer). Under Software Updates go to Automatic Deployment Rules and click Create Automatic Deployment Rule. Give it a name, such as Office 365 Monthly Updates, and select the target collection that contains your clients that need updating. Click Next, and Next again and now select the criteria for updates in the ADR.

Select the following options:
Date Released or Revised: Last 1 month
Product: Office 365 Client
Superseded: No
Title: -semi-annual OR -Monthly Channel (Targeted)

ADRCriteria

Those two items in the Title field (-semi-annual and -Monthly Channel (Targeted)) means exclude any updates with ‘semi-annual’ or ‘Monthly Channel (Targeted)’ in the name. This is because I only want the Monthly Channel updates in my ADR. If you prefer to get the semi-annual updates in yours, do not add that and add ‘-Monthly Channel Version’ to your title instead.

Click Preview to ensure you’re getting what you expect. If not, the updates may not have synchronized yet.

ADRUpdatesPreview

Click Next and select the schedule you want this ADR to evaluate on. Office 365 client updates are released every month (for monthly channel) but not on any particular day, so I have this rule run toward the end of each month to hopefully catch that month’s client update.

ADRSchedule

Click Next and select when you want these updates to be pushed to users. This will depend on your organisations patching schedules and agreements, however I set both the available time and deadline to As soon as possible. This is because I want these updates to be delivered to users as soon as their SCCM client receives the notification of the update.

On the next screen, this is where you need to select specific options to get what I consider to be the best user experience for the Office 365 client updates. In User notifications select Hide in Software Center and all notifications. Under Deadline behaviour tick Software Update Installation, and under Device restart behaviour tick to suppress updates on both Servers and Workstations.

ADRDeploymentSettings

Okay, time for a tangent to explain how this is beneficial to the Office 365 update user experience. If you select Display in Software Center for the user experience and omit the system restart suppression the user will be notified that new updates are available. If they go to Software Center, find the update and click Install they will be presented with the following dialog:

SoftwareCenterConfirmClientUpdate

As it suggests, when they click Install any Office applications they have open will close and the user will think they need to wait for the update to complete before they can continue to work. On top of that, when the update does complete, it will prompt the user to reboot their PC.

SoftwareCenterRebootPrompt

The problem is that the user waiting, and rebooting are a waste of their time. Office is able to install updates in the background while the user is working and only actually needs the user to close the apps right at the end of the install to complete the update. Office prompts the user to complete this step by means of a banner that appears in any of the Office apps that the user opens after the update has finished doing what it can. They can then click Update now at their leisure, and because most of the update process has taken place behind the scenes, the users’ downtime is only a few minutes. Office will even re-open the apps the user had open when it is complete!

OfficeUpdateBanner

So, to mitigate this sub-par user experience, the deployment settings for the ADR should be set to Hide in Software Center and all notifications, with the update allowed to install once the deadline is reached and all restarts supressed. From the users’ point of view, they will not see any indication that Office is being updated until they see the banner in their app prompting them to Update now. They can ignore this until a time that suits them, or it can just happen at the end of the day when they shut down their machine and pack up for the day. And better still, no unnecessary restart prompt.

Let’s get back to that ADR, there isn’t much left to do. Click Next and Next again to get to the Deployment Package page. Create a new deployment package (or add to an existing one, if you wish) and click Next. Continue through the ADR wizard, selecting the download location and which languages you wish to download and finally complete the wizard. Select your new ADR and click Run Now in the ribbon to get the Deployment Package and Software Update Group created. Be aware that this will also create the deployment to the client collection you selected at the start of the process, so make sure that’s acceptable! If it’s not, you may wish to change the deployment collection to a collection containing test clients or just your own machine at first to test that the user experience is what you expect it to be.

And that’s it! Office 365 client updates deployed to your users in the best possible way.
