Installing Remote Server Administration Tools (RSAT) for Windows 10 1809 (including SCCM deployment)

Starting in Windows 10 1809 and continuing in future versions of Windows 10, the Remote Server Administration Tools are an optional feature that can be installed from within the OS, rather than you having to download them from Microsoft separately. This new approach fixes the issue that the tools would be uninstalled every time you install a Windows 10 feature update.

This does have a downside though, which is that Windows must go out to an update source to get the source files for RSAT (they are not included in the /Sources/sxs directory like the .NET 3 Framework source files are). This means you may have to allow clients to go out to Windows Update if they are installing RSAT!

The quick and dirty way to install all RSAT components is to open an administrative PowerShell window and use the command:

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'RSAT')} | %{Add-WindowsCapability -Name $_.Name -Online

This will look for all features that have RSAT in the name and install them.

If you get an error 0800f0954 it means the source location could not be reached. This may be because the machine you’re attempting to install RSAT on doesn’t have internet access or is configured to go to a WSUS or SCCM server for updates. If it’s the latter, you can enable a GPO which allows Windows to go to Windows Update for optional component installations only (while still getting regular updates from WSUS or SCCM). This GPO is in:

Computer Configuration > Administrative Templates > System > Specify settings for optional component installation and component repair

Tick the Download repair content and optional features directly from Windows Update instead of Windows Server Update Services (WSUS) and click OK to set the GPO. You can test this with local group policy to make sure it fixes the issue before deploying it to everyone!

Each of the RSAT components can also be installed individually if you don’t wish to install all of them. The list of RSAT components can be found on this Microsoft Docs page. Use the following PowerShell command to install the component you want, changing the name to match the component you want to install (these are listed as capability names on the linked Microsoft Docs page):

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.BitLocker.Recovery.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

You can install multiple components by simply duplicating the command and changing the name to match another component.

Uninstalling is a little more complicated as you cannot simply use the same catch-all PowerShell command to uninstall as you can to install. This is because some of the RSAT components have dependencies and if you try to uninstall them all the dependancies  will remain installed. To get around this, you can uninstall them in a specific order to ensure that all the dependant components are removed first.

I use the following order:

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.BitLocker.Recovery.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.CertificateServices.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.DHCP.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.Dns.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.FailoverCluster.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.FileServices.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.IPAM.Client.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.LLDP.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.NetworkController.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.NetworkLoadBalancing.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.RemoteAccess.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.RemoteDesktop.Services.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.Shielded.VM.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.StorageMigrationService.Management.Tools')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.StorageReplica.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.SystemInsights.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.VolumeActivation.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.WSUS.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.ActiveDirectory.DS-LDS.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.GroupPolicy.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'Rsat.ServerManager.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}

Making sure that the last three are Rsat.ActiveDirectory.DS-LDS.Tools~~~~0.0.1.0, Rsat.GroupPolicy.Management.Tools~~~~0.0.1.0 and Rsat.ServerManager.Tools~~~~0.0.1.0 seems to fix issues with dependant components.

Creating an SCCM application to deploy RSAT

To create an application in SCCM you will need three things: An install command, an uninstall command and a detection method. To cover the install and uninstall command, let’s create a PowerShell script with an install and uninstall function that can be called from the command line. The following PowerShell script is used to install and uninstall all RSAT components; if you want to pick and chose the ones you install or uninstall, modify it accordingly.

## Install all RSAT components
Function InstallRSAT {
    Get-WindowsCapability -Online | Where-Object {($_.State -notmatch 'Installed') -and ($_.Name -match 'RSAT')} | %{Add-WindowsCapability -Name $_.Name -Online}
}

## Uninstall each RSAT component so that no dependancies are left behind
Function UninstallRSAT {
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.BitLocker.Recovery.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.CertificateServices.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.DHCP.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.Dns.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.FailoverCluster.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.FileServices.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.IPAM.Client.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.LLDP.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.NetworkController.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.NetworkLoadBalancing.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.RemoteAccess.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.RemoteDesktop.Services.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.Shielded.VM.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.StorageMigrationService.Management.Tools')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.StorageReplica.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.SystemInsights.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.VolumeActivation.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.WSUS.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.ActiveDirectory.DS-LDS.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.GroupPolicy.Management.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
    Get-WindowsCapability -Online | Where-Object {($_.State -match 'Installed') -and ($_.Name -match 'Rsat.ServerManager.Tools~~~~0.0.1.0')} | %{Remove-WindowsCapability -Name $_.Name -Online}
}

## Get the parameter passed to the script
$DeploymentType=$args[0]

## Run the install or uninstall function
if ($DeploymentType -eq "Uninstall") {
    UninstallRSAT
}

else {
    InstallRSAT
}

Copy that script and save it as Install-RSAT.ps1. Create your application in SCCM and go through the wizard, giving it a name, publisher and version. The source will be the location where you saved Install-RSAT.ps1. When you get to the install and uninstall commands in the wizard, you can use the following commands:

To install:
powershell.exe -ExecutionPolicy Bypass -File .\Install-RSAT.ps1 -DeploymentType Install

To uninstall:
powershell.exe -ExecutionPolicy Bypass -File .\Install-RSAT.ps1 -DeploymentType Uninstall

Next up is the detection method. For this, you will need to use a PowerShell detection method. The PowerShell will simply check that the RSAT optional components have their install state set to Installed:

$installed = Get-WindowsCapability -Online | where name -like RSAT* | where state -like Installed | select name
if ($installed) {
    return $true
}

That should be all you need! Deploy that to a Windows 10 1809 device and the user should be able to install RSAT from Software Center… as long as their device can go online to reach the source files.

Download Window 10 Enterprise 1809 with the Media Creation Tool (including en-GB and other language versions)

The October 2018 release of Windows 10 has just dropped and is now availabe to download using the Media Creation Tool. Using the GUI you can download the consumer ISO which contains the Home, Professional and Education SKUs of Windows 10.

If you want to download the Enterprise version of Windows 10, but don’t have access to Microsoft VLSC or Action Pack subscriptions, it is possible to download it using the Media Creation Tool if you know the right command line switches.

To download Windows 10 Enterprise 1809 using the Media Creation Tool, log in with a local administrator account (for some reason it isn’t good enough to  run the tool using Run as administrator, you actually do have to be logged in as an administrator) and download the tool. Open a CMD prompt and change directory to the directory you saved the Media Creation Tool in, and enter the following command:

MediaCreationTool1809.exe /Eula Accept /Retail /MediaArch x64 /MediaEdition Enterprise

When you’re prompted for a product key, you can use the Windows 10 Enterprise KMS client key from this site on Microsoft Docs.

This will download an ISO that contains the various Enterprise SKUs (Enterprise, Enterprise N,  Education, Education N, Professional and Professional N) with en-US installed and set to default. If you’d prefer to get en-GB, use the following command:

MediaCreationTool1809.exe /Eula Accept /Retail /MediaLangCode en-GB /MediaArch x64 /MediaEdition Enterprise

This will download an ISO containing the same SKUs as above, but with en-GB installed and set to default.

As far as I can tell, this works for any of the language pack region tags listed on this site. So for example, to download Windows 10 Enterprise 1809 with French installed and set to the default language, you can use this command:

MediaCreationTool1809.exe /Eula Accept /Retail /MediaLangCode fr-FR /MediaArch x64 /MediaEdition Enterprise

If you want to download the 32-bit version of Windows 10 Enterprise instead, you should change /MediaArch to x86.

When you have downloaded the ISO you may unpack it to find that the it does not contain an install.wim, but instead contains install.esd in the sources directory. Depending on what you are doing, you may need the .wim file (for example, if you’re planning to use it with SCCM). Thankfully obtaining a .wim file from the .esd is quite straightforward using DISM.

Open a CMD prompt and use the following command (changing the path for /WimFile to match where your install.esd file is):

dism.exe /Get-WimInfo /WimFile:C:\Temp\Windows10_1809\sources\install.esd

This will list each of the SKUs in the install.esd file. Make a note of the index of the SKU you want (in my case, I want the Enterprise SKU which is index 3).

DISM Get-WimInfo

Now use the following command to create a install.wim file which contains the SKU you want:

dism.exe /Export-Image /SourceImageFile:C:\Temp\Windows10_1809\sources\install.esd /SourceIndex:3 /DestinationImageFile:C:\Temp\Windows10_1809\sources\install.wim /Compress:max /CheckIntegrity

Make sure the path for /SourceImageFile and /DestinationImageFile are correct for you and change the /SourceIndex to match the index you noted earlier.

DISM Convert ESD

Once that is done you can delete the install.esd file if you want, to save space.

This process also works with earlier versions of Windows 10.

Increasing the maximum run time for Windows 10 and Windows Server 2016 cumulative updates

One of the things I have noticed since starting to deploy Windows Server 2016 is that the cumulative updates can fail to install when deployed from SCCM. It starts to run but then times out due to the maximum run time having been reached. By default this is set to 10 minutes. However due to the updates being larger and taking longer to install than updates prior to the cumulative updates era 10 minutes doesn’t seem to be long enough. The fix for this is to simply increase the maximum run time for cumulative updates for both Windows Server 2016 and Windows 10 from 10 minutes to 30 minutes.

Screen Shot 2017-06-05 at 23.12.35

Screen Shot 2017-06-05 at 23.12.47

This is a bit tedious as you’ll have to do it every month for both Windows Server 2016 and every version of Windows 10 you have in your environment. Hopefully Microsoft soon catches on to this and changes the default run time to 30 minutes so that this ceases to be an issue. There is already a Configuration Manager UserVoice entry for this idea, so if you’re reading this, pop over and vote to increase its visibility!
